IP Speaker for SIP Endpoint Paging or Multicast Paging / Background Music, and Making Standard or Emergency SIP Calls

Find A Distributor

Product Details

The Viking model 40TB-IP Talk-Back Ceiling / Wall Speaker enables two-way conversations via SIP and also allows for standard paging and background music via multicast. The Talk-Back Speaker easily connects with a single CAT5/6 cable from your PoE switch. Its shallow depth allows the speaker to be conveniently mounted in a standard 2″ x 4″ stud wall or ceiling.

An auxiliary switch input allows a hard wired wall button to initiate a SIP call. Alternately, an optional wireless remote call button can be used (Viking model BTR-3, sold separately). A momentary button press will initiate a standard call, and holding the button for 3 or more seconds will initiate an emergency call. The remote can also be used to adjust the speaker volume. The LED on the 40TB-IP can be programmed to blink when there is call activity.

The integrated microphone enables talk-back and also monitors room noise to automatically increase speaker volume when necessary. Line-level audio output connections are provided for connecting to an external amplifier. A built-in 6 watt class D amplifier with speaker output connections is also provided to directly drive additional analog 8 Ohm speakers.

A programmable relay output is provided for activating door locks, strobe lights, external amplifiers, etc.


Applications

  • Amplified SIP endpoint or multicast IP paging for:
    • schools
    • hospitals
    • retail stores
    • office spaces, etc.
  • Provide background music and sound masking
  • Make standard and/or emergency SIP phone calls via hands free talkback speaker
  • Background music and emergency calls for:
    • elevator applications
    • retail stores
    • office spaces, etc.
  • No room next to your door for mounting a Entry Phone? Mount the 40TB-IP in the ceiling above the door and use the existing door bell switch to activate a call.

Downloads


Videos


Features

  • PoE powered (class 3, <13 Watts)
  • Use with an optional BTR-3 wireless remote to activate calls or adjust speaker volume
  • Paging prioritization
  • Plays audio from multicast
  • SIP endpoint or multicast group member
  • Supports up to 10 multicast paging groups
  • Add an optional SL-2 blue, green, red or amber strobe light (see DOD 242)
  • Blue call status LED indicator
  • SIP compliant (see product manual for list of compatible IP-PBX phone systems)
  • Automatic Noise Canceling (ANC) feature for operation in noisy environments
  • Viking’s proprietary VOX switching eliminates the need for “Push to Talk” mode
  • Selectable auto-answer feature for monitoring
  • Autoprovisioning via Viking programming software
  • Built-in high efficiency 6 Watt class D amplifier
  • Relay for activating door locks, strobe lights, external amplifiers, etc.
  • SIP / Multicast: SIP page, SIP page and zoned multicast stream, zoned multicast receive
  • Support for access code to prevent unwanted SIP calls
  • Line-level audio output for connecting to an external amplifier
  • Hangs up on: busy signal, time-out, or touch tone command
  • Network remote speaker volume control
  • Can drive additional external analog speakers for greater coverage
  • Mounting: Blind mounts into 9.5″ hole, clearance requirement of 3.45″ (87.3mm) above 0.5″ gypsum board ceiling
  • Heavy duty back box protects speaker and circuitry against plenum dust
  • Automatic Gain Control (AGC) to automatically increase ring volume to compensate for ambient noise
  • Diagnostics (for testing mic, speaker & relay)

Specifications

  • Power: PoE class 3 (<13 Watts)
  • Overall Dimensions: 11″ x 11″ x 4″ (279mm x 279mm x 102mm)
  • Back Box Dimensions: 9.25″ x 9.25″ x 3.45″ (235mm x 235mm x 88mm)
  • Shipping Weight: 5.0 lbs (2.27 kg)
  • Operating Temperature: -40°F to 140°F (-40°C to 60°C)
  • Humidity: 5% to 95% non-condensing
  • Audio Codecs: G711u, G722, and G711a (SIP only)
  • Network Compliance: IEEE 802.3 af PoE, SIP 2.0 RFC3261, 100BASE-TX with auto cross over
  • Sensitivity: 96dB / 1W / 1M SPL
  • Maximum Output Level: 105 dB SPL @ 1M (with no additional speakers connected)
  • Amplifier: 6 Watt class D (capable of driving up to five additional 8 Ohm speakers connected in parallel)
  • Connections: (1) RJ45 10/100 Base-T, (8) cage clamp screw terminals on pluggable connector

Certifications

  • FCC Part 15
  • SIP

Tones

To download a tone for use on your product, right click on the Download icon and select "Save Link As" (instructions may vary slightly per web browser)

Tone Description Preview Download
Normal Ring Normal Ring Cadence N/A
Double Ring Double Ring Cadence N/A
Short Short Long Short Short Long Ring Cadence N/A
Short Long Short Short Long Short Ring Cadence N/A
One Beep One Beep N/A
Two Beeps Two Beeps N/A
Three Beeps Three Beeps N/A
