E-10A – Viking Electronics

Entry Phone with Black Aluminum Faceplate

Find A Distributor

Product Details

The E-10A is a telephone line powered entry phone designed to provide two-way handsfree communication. When the “Call” button is pressed, the E-10A will come off-hook and will remain off-hook until a CPC signal is detected, the programmed timeout has elapsed, a busy signal is detected, or the call goes silent, making the unit automatically disconnect.

The E-10A can be used with a Viking K-1900-5 or K1900-30 dialer, or connected directly to a CO line or analog PABX / KSU station when programmed as a ringdown circuit. If a line or station is not available, a Viking DLE-200B ringdown circuit can be used. One to four E-10A speaker phones can share an existing phone line in a house or small business when used with a Viking C-200, C-250 or C-2000B Entry Phone Controller.

For outdoor installations where the unit is exposed to precipitation or condensation, use model E-10A-EWP. For more information on Enhanced Weather Protection (EWP), see DOD 859.


Applications

  • Door or gate communication, business delivery entrances
  • Provide unique front and back door chimes and paging when used with a Viking C-2000B and a Viking SLP-1 or SLP-4
  • Residential, commercial, and industrial door security
  • Use with a Viking K-1900-5 or K-1900-30 for automatic speed dialing on telephone lines or analog PABX / KSU station ports
  • Use on any analog PABX station port with programmable ringdown capability

Downloads


Videos


Features

  • Alternate action call button to place or cancel a call
  • Intelligent call progress detection for automatic hang-up on CPC, silence, busy signal, or time out
  • Telephone line powered
  • Adjustable microphone and speaker volume
  • Programmable maximum call length
  • Selectable auto-answer feature allows remote monitoring
  • Two-way handsfree communication
  • Programmable VOX (mic / speaker) switching speed
  • Vandal resistant black powder painted aluminum faceplate with heavy duty 316 stainless steel call button and mounting gasket
  • Flush mount using the included rough-in box or surface mount using a VE-5×5 Surface Mount Box (DOD 424)

Specifications

  • Power: Telephone line powered (18VDC / 20mA minimum)
  • Overall Dimensions: 5″ x 5″ x 2.25″ (127mm x 127mm x 57.2mm)
  • Rough-In Box Dimensions: 4″ x 4″ x 2.15″ (102mm x 102mm x 55mm)
  • Shipping Weight: 2 lbs (0.91 kg)
  • Operating Temperature: -30°F to 150°F (-34°C to 65°C)
  • Humidity: 5% to 95% non-condensing
  • Maximum Speaker Volume: 70dB SPL @ 1m
  • Ring Voltage: 25VRMS minimum
  • Minimum CPC Disconnect Time: 300ms
  • REN: 0.8A
  • Connections: (2) Gel-filled butt connectors

Certifications

  • FCC Part 68
  • FCC Part 15
