Black IP Entry Phone with HD Video and Enhanced Weather Protection

Find A Distributor

Product Details

The X-35-BK-EWP is a VoIP HD Video Entry Phone designed to provide HD video and reliable handsfree voice communication for SIP VoIP phone systems and service providers. The X-35-BK-EWP’s built-in IP video camera has H.264 video compression, low light sensitivity, a wide viewing angle of 126 degrees, and can output dual video streams of up to 1080p resolution.

The X-35-BK-EWP entry phone can dial up to 5 programmable numbers and be programmed remotely via its built-in Web GUI. On-board 2 Amp relay contacts are provided for activating door strikes or gate controllers. An optional Viking RC-4A Secure Relay Controller can also be used.

The X-35-BK-EWP entry phone will flash the blue LED during dialing and automatically light the LED when the call is answered. The unit is PoE class 2 powered.

The X-35-BK-EWP is equipped with Enhanced Weather Protection (EWP), ideal for outdoor installations where the unit is exposed to precipitation or condensation. EWP products feature foam rubber gaskets, sealed connections, gel-filled butt connectors, as well as urethane or thermal plastic potted circuit boards. For more information, see DOD 859.

Want to learn more about X-35? Click Here


  • Gate Entrance
  • Parking ramps/lots
  • ATM machines
  • Medical centers
  • Lobbies
  • Entryways
  • Stadiums
  • Convention centers
  • Public access areas



  • SIP compliant (see compatible IP-PBX Phone Systems / Service Providers)
  • Multicast paging compatible
  • ONVIF Profile S compliant
  • 126° wide viewing angle
  • H.264 and MJPEG video compression
  • Dual-Stream HD video allowing for up to two 1080p video streams
  • Selectable video resolutions: 352 x 288, 704 x 526, 720p and 1080p
  • Remotely programmable via Web GUI
  • Gigabit Ethernet for up to 1000 Mbps
  • 2 Amp relay contacts for door/gate or optional SL-2 strobe light (DOD 242)
  • Blue backlit 316 stainless steel push button switch
  • PoE powered (class 2, < 6.5 Watts)
  • Automatic Noise Canceling (ANC) for proper operation in noisy environments
  • Network downloadable firmware
  • T-10 Torx security screws for added security
  • Can be used with optional RC-4A Secure Relay Controller (DOD 582)
  • Handsfree operation
  • Vandal resistant 316 stainless steel prevents corrosion
  • Laser etched graphics on model X-35-SS
  • Cycles through up to five backup phone numbers on busy or no-answer
  • Optional Enhanced Weather Protection (EWP), EWP products are designed to meet IP66 Ingress Protection Rating (DOD 859)
  • Extended temperature range: -40° F to 140° F
  • Available in 316 Stainless Steel, Textured Black, or Oil-Rubbed Bronze finish
  • Volume adjustments for microphone and speaker
  • Flush mounts in a standard double gang electrical box (not included), or surface mount using an optional Viking Surface Mount Box (DOD 424)
  • Diagnostics for testing microphone, speaker, and relay


  • Power: PoE class 2 (< 6.5 Watts)
  • Maximum Sound Pressure: 90 dB SPL @ 1m
  • Operating Temperature: -40° F to 140° F (-40° C to 60° C)
  • Humidity – Standard Products: 5% to 95% non-condensing
  • Humidity – EWP Products: Up to 100%
  • Video Codecs: H.264 and MJPEG
  • Audio Codecs: G711u, G711a, G722
  • Network Compliance: IEEE 802.3 af PoE, SIP 2.0 RFC3261, 1000BASE-T with auto cross over
  • Connections: (1) RJ45 100/1000 Base-T, (3) gel-filled butt connectors


  • EWP
  • IP66
  • SIP
